C12300 copper sheet, stands out for its excellent mechanical properties and corrosion resistance. Phosphorus-refined, it possesses high tensile strength and good elongation, making it suitable for a wide range of structural material requirements. In harsh conditions such as marine environments, C12300 copper sheet exhibits excellent corrosion resistance, ensuring long-term stable use.
As a high-quality metal material, C12300 copper plate is widely used in oil and gas pipelines, condensers, heat exchangers and other critical areas. Its excellent conductive properties and processing performance make it highly favored in the electronic, electrical and construction industries as well. Whether it is used as a structural support or conductive medium, C12300 Copper Sheet can play an excellent role in meeting the needs of various industrial applications.
| Physical Property | Specification |
|---|---|
| Tensile Strength (MPa) | 215 – 275 |
| Elongation (%) | ≥ 25 |
| Hardness (HV) | 55 – 100 |
| Density (g/cm³) | Approx. 8.96 |
| Electrical Conductivity (% IACS) | Lower than pure copper due to phosphorus content |
| Melting Point (°C) | Approx. 1083 |
| Thermal Expansion Coefficient (μm/m·K) | Depends on temperature range |
| Thermal Conductivity (W/m·K) | Lower than pure copper due to phosphorus content |
